| PERFORMANCE |
| Model | Discharge Height(m) | 0.0 | 2.0 | 4.0 | 6.0 | 8.0 | 10.0 | |
| EMCNP24 | Liters Per Hour | 28 | 24 | 20 | 18 | 16 | ||
| Model | Discharge Height(m) | 0.0 | 3.0 | 6.1 | 9.1 | 12.2 | 15.2 | |
| EMCNP40 | Liters Per Hour | 40 | 34 | 30 | 24 | 20 | 18 | |
| SPECIFICATIONS |
| Model | EMCNP24 | EMCNP40 | ||
| Liquid Temperature Range | 0℃-50℃ | |||
| Volts | 120VAC/220VAC(customizable) | |||
| Hz | 50 Hz/60Hz | |||
| Operating level | Non-Continuous | |||
| Max.Current | 50 mA | |||
| Max.Power | 3W | |||
| Max.Head | 10m | |||
| Capacity | 60 ml | |||
| Noise Leve | 19 dB | 21 dB | ||
| Max.Flow | 24 L/H | 40 L/H | ||
| Applicable air conditioning power | 8 KW(30,000 btu/hr) | 15Kw(45,000 btu/hr) | ||
